HPE Networking CW 2050 48G 4F Switch Hub

HPE Networking CW 2050 Switch Series

Enterprise Smart Switch with Flexible and Comprehensive Connectivity Ports

The HPE Networking CW 2050 S6X70A is a Layer 2 Managed Switch from HPE Aruba Networking, designed for small and medium businesses and branch offices. It features 48 x 10/100/1000BASE-T ports for connecting numerous network devices and 4 x 1G/2.5G SFP uplink ports, allowing for flexible network design and diverse applications.

48 Gigabit Ports with Various High-Speed Connectivity Ports

Supports 48 x 10/100/1000BASE-T for connecting computers, printers, access points, CCTV cameras, servers, and other network devices, along with 4 x 1G/2.5G BASE-X SFP ports for Uplink connections to Core Switches or central network devices. This switch offers flexible connectivity, suitable for network systems that need to support a large number of devices.

1G/2.5G SFP Uplink Ports for Flexible Connectivity

The 4 x 1G/2.5G BASE-X SFP ports support network connections via suitable transceivers, increasing connection options between the switch and core switches, servers, or central network systems. This is ideal for infrastructure designs that require high-speed ports and flexible connectivity.

Powerful Data Transfer Performance with Switching Capacity up to 116 Gbps

The HPE Networking CW 2050 S6X70A supports a switching capacity of up to 116 Gbps and a maximum throughput of 86.30 Mpps, with a 1MB packet buffer, enabling efficient handling of large volumes of data. It is suitable for business networks with high traffic and numerous connected devices.

Supports Two-Switch IRF Stack for Network Expansion

Supports a Two-Switch IRF Stack of up to 2 switches, allowing devices to operate as a single system. This enhances management flexibility and supports future network expansion. HPE states that IRF can combine two switches to act as a single logical device, improving system continuity and flexibility.

Supports Various Management Methods with SmartMC and IMC

Manageable via Web GUI, Command Line Interface (CLI), SmartMC, HPE IMC, AirWave, SNMP, and REST API, allowing administrators to configure, monitor, and manage the network as needed. It supports both web-based management and integration with enterprise network management systems.

Built-in Power Supply with Enterprise Design

The device comes with a fixed internal power supply, supporting 90–264V AC and consuming approximately 24W AC. It is a Non-PoE switch (no power over Ethernet system), suitable for network systems where power delivery to end devices is separate from the switch itself.

Operating Environment Supports Office and Enterprise Use

Supports operating temperatures from -5°C to 45°C and relative humidity of 5%–95% (non-condensing). With dimensions of 440 × 260 × 44 mm, it is suitable for installation in standard rack cabinets, making it ideal for server rooms, network rooms, and offices.

Suitable for Businesses and Branch Offices

The HPE Networking CW 2050 S6X70A is a switch that combines numerous connectivity ports with high-speed uplink ports. It supports 48 x 10/100/1000BASE-T, 4 x 1G/2.5G BASE-X SFP, Two-Switch IRF Stack, and management via SmartMC, IMC, SNMP, and REST API, along with a Limited Lifetime Hardware Warranty. This makes it ideal for enterprises, small to medium-sized businesses, and branch offices that require a flexible and expandable network system.
