HPE Networking CW 2150 24G 4P Switch Hub
HPE Networking CW 2150 24G 4P Switch Hub is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Exchange available within 7 days of receipt if conditions apply
1. The warranty applies only in cases where the product is damaged due to a malfunction resulting from a manufacturing defect
2. Dead pixel warranty applies for Laptop products and computer monitors with 5 or more dead pixels
3. The store delivered the wrong product
Authentic product with official warranty: Throughout its lifespan
Payment
Payment
Payment
- Bank Deposit
- Full Payment via Credit Card (All Major Banks Accepted)
- Cash on Delivery (COD)
Delivery and Shipping
Delivery and Shipping
Delivery
- Express Delivery within 3 Hours Service fee 300 THB
(Available only in Bangkok, Metropolitan Area, and Chiang Mai city) - Domestic shipping packed and delivered by Best Express
- Pick up your order at the nearest branch
HPE Networking CW 2150 24G 4P Switch
HPE-S6X50A
-
Brand: HPE Networking / HPE Aruba Networking
-
Model: CW 2150 24G 4P Switch (S6X50A)
-
Type: Enterprise-class Layer 3 Managed Smart Switch for Small and Medium Businesses and Branch Offices
-
Ports and Connectivity:
- 24 × 10/100/1000BASE-T RJ-45
- 4 × 1G/10GBASE-X SFP+ for high-speed Uplink connectivity
- 1 × RJ-45 Console Port
- 1 × USB Type-C Console
- 1 × OOBM
- 24 × 10/100/1000BASE-T RJ-45
-
PoE Type: Non-PoE (No Power over Ethernet)
-
Forwarding Capacity: 128 Gbps
-
Throughput: 95.2 Mpps
-
Processor: ARM 1.2 GHz Dual Core
-
Memory: 1GB SDRAM
-
Flash Memory: 512MB Flash
-
Packet Buffer: 1.5MB
-
MAC Address Table: 16K addresses
-
IPv4 Routes: 1,500
-
IPv6 Routes: 512
-
VRF: Supports up to 32 Instances
-
Stacking: Supports up to 9 Switches with Intelligent Resilient Fabric (IRF)
-
System Management: Web GUI, CLI, SmartMC Web, HPE IMC, AirWave, SNMP, and REST API
-
Cooling System: Fanless
-
Power Supply: Fixed Internal Power Supply, AC 90–264V
-
Power Consumption: Idle 6W, Typical 16W, Full Load 21W
-
Operating Environment: Temperature -5°C to 50°C, Relative Humidity 5%–95% Non-condensing
-
Installation: Supports installation in standard EIA 19-inch racks
-
Dimensions (W x D x H): 440 × 160 × 44 mm
-
Weight: Up to 2.0 kg
- Warranty: Limited Lifetime Hardware Warranty
HPE Networking CW 2150 Switch Series
Enterprise-grade Switch with Layer 3 and 10GbE Uplink
The HPE Networking CW 2150 model S6X50A is a Managed Layer 3 switch designed for enterprises, small and medium businesses, and branch offices. It comes with 24 Gigabit Ethernet ports and 4 1G/10G SFP+ uplink ports, supporting both internal network device connectivity and connections to core switches or central network devices.
24 × 10/100/1000BASE-T with 4 × 1G/10G SFP+
Supports 24 10/100/1000BASE-T ports for connecting computers, printers, access points, CCTV cameras, servers, and other network devices, along with 4 high-speed 1G/10GBASE-X SFP+ ports for uplinks, increasing flexibility in network infrastructure design.
High Data Forwarding Capacity of up to 128 Gbps
The HPE Networking CW 2150 S6X50A supports a forwarding capacity of up to 128 Gbps and a maximum throughput of 95.2 Mpps, with a 1.5MB packet buffer, enabling efficient handling of large volumes of data. It is suitable for enterprise networks with high traffic and a need for fast connectivity.
Supports Layer 3 and Dynamic Routing
In addition to Layer 2 capabilities, the CW 2150 supports Layer 3 functions such as IPv4 and IPv6 Static Routing, Policy-Based Routing, RIP, and OSPF, as well as Multi-VRF Customer Edge, allowing for flexible network design with segmenting and routing between networks.
Supports Stacking of up to 9 Switches
Supports Intelligent Resilient Fabric (IRF) with up to 9 switches, allowing multiple devices to operate as a single logical device. This enhances flexibility, continuity, and scalability of the network system, making it suitable for organizations that need to accommodate future system growth.
Diverse Management Options with SmartMC and HPE IMC
Supports management via Web GUI, Command Line Interface (CLI), Smart Management Center (SmartMC), HPE Intelligent Management Center (IMC), AirWave, SNMP, and REST API, allowing administrators to configure, monitor, and manage devices through various channels.
Non-PoE with Fanless Design
The HPE Networking CW 2150 model S6X50A is a Non-PoE switch, meaning it does not provide power over Ethernet cables. It uses a fixed internal power supply supporting AC 90–264V and features a fanless design, which reduces noise, making it suitable for offices and environments that require a quiet working atmosphere.
Designed for Standard Rack Mounting
The device measures 440 × 160 × 44 mm and weighs up to 2.0 kg. It supports installation in standard EIA 19-inch racks, making it ideal for installation in network rooms, server rooms, and offices that require organized network equipment.
Suitable for Enterprises and Branch Offices
With 24 Gigabit ports, 4 1G/10G SFP+ uplink ports, Layer 3 capabilities, Dynamic Routing, and IRF Stacking of up to 9 switches, the HPE Networking CW 2150 S6X50A is suitable for enterprises, small and medium businesses, and branch offices that require a high-performance switch with enterprise-level network management.
